Description

9135D GEZE Boxer Size 2-4 Concealed Door Closer and Pivot Set For Double Action Doors

• Maximum door weight: 130kg
• Maximum door width: 1100mm
• Minimum door width: 652mm
• Minimum door thickness: 40mm (44mm for fire rated doors)
• Maximum opening angle: 120°
• Independently tested to BS EN 1154
• Adjustable power size 2-4
• Adjustable closing speed
• Adjustable backcheck
• Adjustable latching action
• Slide arm and concealed frame mounted channel
• Supplied c/w top centre, floor pivot and bottom strap
• Supplied with universal fixings to suit timber or metal doors and frames
• Maximum recommended opening angle 120° in either direction, a door stop or an XX9133CS cushion stop can be used to help achieve this
• 10 year warranty
