Description
98181N Allgood Hardware Electromagnetic Hold Open & Free-swing Overhead Door Closer
- Independently tested to BS EN 1155:1996 / BS EN 1154:1996
- Fig 1 & Fig 61 Classification 3-8-3/4-1-1-3
- Fig 6 Classification 3-8-3-1-1-3
- Maximum door weight: 80kg
- Maximum door width: 1110mm
- Universal Application Figure 1 & 6
- Mechanism Rack & Pinion
- Non handed
- Incorporated in successful fire tests and assessed to BS EN 1634-1 and BS 476 Pt 22 up to 120 mins on timber doors
- Certifire approved CF 5517
- CE Marked
- Opening angle Fig 1 / 61 EN3 – 180°
- Opening angle Fig 1 / 61 EN4 – 110°
- Opening angle Fig 66 EN3 – 170°
- Fig 1 & Fig 61 Adjustable Power size 3-4
- Fig 6 Adjustable Power size 3
- Adjustable closing speed
- Adjustable latching action
- Power supply required = 24v DC
- Current draw = 95mA
- Supplied c/w black power transfer loop, frame mounted connection box and on/off switch
- 2 year manufacturing warranty
Requests for mechanical or fire test reports please email [email protected]
Please note:
We’re delighted that the 98181N Allgood Hardware Electromagnetic Hold Open & Free-swing Overhead Door Closer is CCPI Assessed – helping to provide greater confidence to product users that the product information for these products is clear, accurate, accessible, up-to-date and unambiguous.
